Automotive 3D sensing with advanced VCSEL laser technology

VCSELs are gaining momentum in advanced automotive 3D sensing applications.

Using VCSEL laser technology for advanced automotive 3D sensing

Automotive technologies can leverage the power of VCSELs (Vertical-Cavity Surface-Emitting Laser) for all sorts of sensor applications inside and outside the cabin. Driver monitoring systems, cabin interior monitoring, illumination, smart lighting, LiDAR, autonomous driving, and Advanced Driver-Assistance Systems (ADAS) are just a few examples of emerging applications in the industry.

Why use VCSELs for automotive 3D sensing?

A growing number of 3D sensing applications are emerging in automotive design and in autonomous vehicles such as LiDAR, driver and occupant monitoring and driver control systems. In the automotive sector, VCSEL solutions for automotive sensors are ideal for compact, high productive and high reliability component designs.

Small footprint

VCSEL solutions can come in small packages. Their footprint is up to 5-10 times smaller than competing technologies.

Extended functionalities

Achieve a smaller footprint and more freedom in optical design by adding smart functionalities to VCSEL diodes, such as monolithically integrating micro-optics.

Solutions for inside and outside the car

VCSELs support vehicle in-cabin and out-cabin solutions. They offer short and long-range solutions for illumination.

Very fast pulsing mode

Ideal for LiDAR applications, low rise and fall times of optical pulses enable ultrashort pulses with high peak power.

VCSEL arrays for next-generation automotive solutions will be standard in a few years. Product and process evaluation are ongoing, as is setting official standards to enable VCSELs to become standard components in vehicles.

Ralph Gudde
VP MARKETING AND SALES AT TRUMPF PHOTONIC COMPONENTS

Let's connect!

Talk to our automotive 3D sensing experts about your application needs and challenges.

Request consultation

How is VCSEL technology used in automotive sensing applications?

Powered by developments in autonomous driving, advanced optical 3D sensing solutions have become critical to ensure safety. VCSELs are extremely eye-safe for car sensors and can support in-cabin monitoring for automotive applications, more specifically driver monitoring. VCSELs also support outside the cabin applications such as LiDAR to control the outer space around passenger cars. VCSELs with monolithically integrated optics offer long lifetime, a small footprint and can be scaled for long-range applications. Various sensors as temperature sensors, oxygen sensors, speed sensors, image sensors, cameras, radar and other functionalities are supported by VCSEL-powered automotive sensor technology.

In-cabin and out-cabin solutions

In-Cabin Sensing

With autonomous and self-driving capabilities rapidly evolving in the automotive industry, vehicle driver and occupant monitoring and driver control systems are absolutely critical. VCSEL sensor technology can be used for vehicle safety monitoring as well as gesture control to automate and for safer and more convenient usage of various consumer applications inside the vehicle. Automotive optical sensing applications can rely on high-performance VCSELs to ensure driver safety.

LiDAR

LiDAR (Light imaging, detection and ranging) is used for proximity sensing or speed sensing. In autonomous driving, LiDAR is a mandatory technology. VCSEL arrays are perfectly suitable for LiDAR applications. Very low rise and fall times of the optical pulses enables ultra-short pulses with high peak powers. Addressability of different segments on the VCSEL arrays can improve the system performance significantly.

Diese Themen könnten Sie auch interessieren

Optical sensing technology for consumer, industrial and automotive applications

Optical sensing technology is widely used in consumer electronics, industrial sensing and automotive or other applications such as IoT. VCSELs can be a cost-effective, versatile and highly reliable light source to support advanced technologies needed for (3D) sensing applications using optical sensors.

autonomous driving with a e-car
Car networks also benefit from VCSELs and photodiodes

Besides innovations in 3D sensing applications, VCSELs and photodiode solutions also offer data communication applications for car networks. Autonomous driving technology requires heavy data processing and optical interconnects for data flow management. Optical signals can leverage VCSELs as a light source to send encrypted transmissions that are decoded by a photodetector at the other end.

ViBo poduct image front
ViBO: VCSEL with integrated backside optics

ViBO is an advanced, cost-effective and easy-to-integrate VCSEL array technology with monolithically integrated micro-optical elements.
